• Hign-concerned Chemical: None
• Zoom type: None
• Zoom: None
• Lens Quantity: Dual Lens
• AI Functions:  Human Detection
• Color Night Vision: Yes
• Operating Temperature: -10°-60°
• IP Rating:  IP67
• Power Mode:  Mains Electricity
• Scene:  Indoor and outdoor
• Megapixels: 8MP
• TF Card: None
• Power Supply:  With Poe
• Internal Storage:  None
• Installation: Ceiling,Normal
• Color:  WHITE
• Audio Output: 1CH BNC
• Minimum Illumination(Lux):  0 Lux with white light
• Viewing Angle: 100°
• Video Compression Format:  H.265,MJPEG,H.264
• IR Distance(m):  White Light Up to 30 m
• Dimensions (L x W x D)(mm):  170*170*150mm
• Power Supply(V):  DC12V/POE (802.3af)
• Power Consumption(W): 8.5 W
• Supported Mobile Systems:  Android,iOS
• Sensor: CMOS
• Model Number: DS-2CD1383G2P-LIUF/SL
• Supported Operating Systems: Windows 11,Windows 10
• Lens (mm):  2mm
• Connectivity: IP/Network Wired
• High Definition: 8.0 Megapixels
• Style: Dome Camera
• Brand Name: HIKVISION
• Origin: Mainland China
• Special Features: Waterproof / Weatherproof
• Certification: CE
• Shell Material: Metal
• Smart home platform:  Other

4K Ultra HD Surveillance Camera – Professional Security Solution

Key Features:

• Camera

• Image Sensor1/2.4" Progressive Scan CMOS

• Max. Resolution4256 × 1888

• Min. IlluminationColor: 0.005 Lux @ (F1.6, AGC ON),0 Lux with light

• Shutter Time1 s to 1/100,000 s

• Day & NightIR cut filter

• Angle AdjustmentPan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°

• Lens

• Lens TypeFixed focal lens, 2 mm

• Focal Length & FOV2 mm, horizontal FOV 180°, vertical FOV 77°

• Lens MountM12

• Iris TypeFixed

• ApertureF1.6

• DORI

• DORI2 mm, D: 50 m, O: 20 m, R: 10 m, I: 5 m

• Illuminator

• Supplement Light TypeIR,White Light

• Supplement Light RangeUp to 30 m

• Smart Supplement LightYes

• IR Wavelength850 nm

• Video

• Main Stream

  50 Hz: 20 fps (4256 × 1888)

  60 Hz: 20 fps (4256 × 1888)

• Sub-Stream

  50 Hz: 20 fps (1200× 536, 960 × 432)

  60 Hz: 20 fps (1200× 536, 960 × 432)

• Video Compression

  Main stream: H.265+/H.265/H.264+/H.264,

  Sub-stream: H.265/H.264/MJPEG

• Video Bit Rate32 Kbps to 16 Mbps

• H.264 TypeBaseline Profile,Main Profile,High Profile

• H.265 TypeMain Profile

• Bit Rate ControlCBR,VBR

• Region Of Interest (ROI)1 fixed region for main stream

• Scalable Video Coding (SVC)H.264 and H.265 encoding

• Audio

• Audio TypeMono sound

• Audio Sampling Rate8 kHz/16 kHz

• Environment Noise FilteringYes

• Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/AAC-LC

• Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)

• Network

• SecurityPassword protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)

• Simultaneous Live ViewUp to 6 channels

• APIONVIF (Profile S, Profile T, Profile G),ISAPI,SDK

• ProtocolsTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, IPv4, IPv6, UDP, QoS, FTP, SMTP, HTTPS, DDNS

• User/Host

  Up to 32 users

  3 user levels: administrator, operator, and user

• ClientiVMS-4200,Hik-Connect

• Web Browser

  Plug-in required live view: IE 11,

  Local service: Chrome 80+, Firefox 80+, Edge 89+

• Image

• Wide Dynamic Range (WDR)120 dB

• SNR≥ 52 dB

• Day/Night SwitchDay,Night,Auto,Schedule

• Image EnhancementBLC,HLC,3D DNR

• Image SettingsRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser

• Privacy Mask4 programmable polygon privacy masks

• Interface

• Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port

• On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB

• Built-In MicrophoneYes,1 built-in microphone

• Built-In SpeakerYes, 1 built-in speaker,Max. power consumption: 2 W, max. sound pressure level: 10 cm: 97 dB.

• Reset KeyYes

• Event

• Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception

• LinkageUpload to FTP/memory card, notify surveillance center, send email, trigger recording, trigger capture, audible warning, strobe light flashing

• General

• Power

  12 VDC ± 25%, 0.83 A, max. 10 W,Ø5.5 mm coaxial power plug,reverse polarity protection,

  PoE: IEEE 802.3af, Class 3, max. 11.5 W

• MaterialBase: Metal, cover: Plastic

• DimensionØ130.1 mm × 109.1 mm (Ø5.1" × 4.3")

• Package Dimension150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")

• WeightApprox. 586 g (1.3 lb.)

• With Package WeightApprox. 760 g (1.7 lb.)

• Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

• Startup And Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

• LanguageEnglish, Turkish, Polish, Romanian, Czech, Slovak, Traditional Chinese, Thai, Vietnamese, Croatian, Slovenian, Serbian, Ukrainian

• General FunctionHeartbeat,anti-banding,password protection,password reset via email

• Flashing Light

  /SRB model: Red and Blue Light

  /SL model: White Light

• Approval

• EMC

  CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,

  IC: ICES-003: Issue 7,

  KC: KN32: 2015, KN35: 2015

• Safety




  CB: IEC 62368-1: 2014+A11,

  BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

• Environment

  CE-RoHS: 2011/65/EU,

  WEEE: 2012/19/EU,

  Reach: Regulation (EC) No 1907/2006

• ProtectionIP67: IEC 60529-2013

1.DS-2CD1383G2P-LIUF/SL 8 MP

2.Wiring cap*1

3.Screw driver*1

4.Screw* 1 lot
5.Location hole paper*1
