Dell PowerEdge R740xd 2U 12 Bay LFF with 4 Bay SFF Flex Bay (Refurbished)

Skip image gallery

$9,000.00

Product number: R740xd 2U 12 Bay

Product information "Dell PowerEdge R740xd 2U 12 Bay LFF with 4 Bay SFF Flex Bay (Refurbished)"

The PowerEdge R740xd delivers a perfect balance between storage scalability and performance. The 2U two-socket platform is ideal for software defined storage, service providers or as virtual desktop infrastructure. The scalable system architecture behind the R740xd with up to 24 NVMe drives creates the ideal balance between scalability and performance. The R740xd versatility is highlighted with the ability to mix any drive type to create the optimum configuration of NVMe, SSD and HDD for either performance, capacity or both. The R740xd is the platform of choice for software defined storage and is the foundation for ScaleIO, VSAN or the PowerEdge XC.

The R740XD supports up to two Intel Xeon Scalable processors, each supporting up to 28 cores per processor.  The R740XD has 24 DDR4 memory slots, 12x per processor allowing a maximum of 3TB of RAM. The R740XD supports flexible storage options with up to 24 NVMe drives or a total of 32x 2.5" or 12x 3.5" drives.
Memory: 24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666MT/s, 3TB max Up to 12 NVDIMM, 192 GB Max Supports registered ECC DDR4 DIMMs only; Choose From Available Options Condition: Tested for full functions, System Ready for Reuse Flex Bay: Optional Rear Flex Bay Front Bezel: Front Bezel Available Network: Choose From Available Network Daughter Card Options Operating System: No Software or O/S Installed Power Supply: Supports 2x Redundant Hot Swap Power Supplies; Choose from Available Options Processor: Up to two Intel Xeon Scalable processors, up to 28 cores per processor Rack Rails: Rack Rails Available Remote Management: iDRAC9 with Lifecycle Controller; Choose From Available Options Shipping Time: All systems usually ship within 3-5 Business days Storage Controller: Supports Dell PERC Controllers; Choose From Available Options Storage: Up to 12x 3.5” SAS/SATA (HDD/SSD); Choose From Available Options Warranty: All servers are fully tested and come with a 90 day warranty

Dell PowerEdge R740xd 2U 12 Bay LFF with 4 Bay SFF Flex Bay

Flex Bay: 4x 2.5 Flex Bays
Processor: 2x Intel Xeon Platinum 8270 2.7GHz 26-Core Processors
Memory: 256GB (2x 128GB) 2933MHz DDR4 Registered Memory
Storage Controller: Dell PERC H730p 12Gbps SAS/SATA Mini Mono RAID Controller with 2GB Battery Backed Cache
Hard Drive (1): 4TB 3.5" 7.2K 6Gbps SAS
Hard Drive (2): 4TB 3.5" 7.2K 6Gbps SAS
Hard Drive (3): 4TB 3.5" 7.2K 6Gbps SAS
Hard Drive (4): 4TB 3.5" 7.2K 6Gbps SAS
Hard Drive (5): 4TB 3.5" 7.2K 6Gbps SAS
Hard Drive (6): No Drive or Tray Installed
Hard Drive (7): No Drive or Tray Installed
Hard Drive (8): No Drive or Tray Installed
Hard Drive (9): No Drive or Tray Installed
Hard Drive (10): No Drive or Tray Installed
Hard Drive (11): No Drive or Tray Installed
Hard Drive (12): No Drive or Tray Installed
Flex Bay Drive (1): No Drive or Tray Installed
Flex Bay Drive (2): No Drive or Tray Installed
Flex Bay Drive (3): No Drive or Tray Installed
Flex Bay Drive (4): No Drive or Tray Installed
Integrated Network Controller: Intel X520/i350 1000BASE-T 2x 1GbE + 2x 10GbE SFP+ Ethernet NDC PN# C63DV
BOSS Card/PCIe Add-On Card: None Installed
PCIe Add-On Card (2): None Installed
Remote Management: iDRAC 9 Express
TPM Module: None Installed
Power Supply: 2x 750W Platinum Power Supplies (100-240V)
4-Post Rack Rail Kit: Dell ReadyRails Sliding Rail Kit
Front Bezel: Bezel Included
Power Cable: 2x 3 Prong Power Cord
TotalServerShield Extended Warranty: Standard 90 Days (Replacement Parts; No Onsite Support)
